Dedicated to providing customers with a full range of special copper tubes solutions
4 Years
| Ask Lasest Price | |
| Brand Name : | Transense |
| Model Number : | CU-DHP;C12000 |
| Certification : | Rohs |
| Price : | USD LME Cu + Fabrication cost |
| Payment Terms : | L/C, D/A, D/P, T/T |
| Supply Ability : | 400 ton one Month |
| Delivery Time : | 3-4 weeks |
Inner Grooved Copper Tubes For solar equipment
Product Description
Inner-grooved Tube,advantage in High heat dissipation performance
and Lightweight.Inner-grooved Tube increases the internal surface
space,while the groove's torsion promotesturbulent flow and
evaporation and condensation heat transfer,resulting inimproved
performance.
Inner Grooved Copper Tubesimproves thermal efficiency of
refrigeration units , enabling the reduction of the size of these
units, whilst reducing the quantity of the refrigeration mixture
required.Inner-grooved Tube has the advantages of high efficiency
and energy saving, high cleanness of inner and outer surface, super
bright, uniform and compact structure, high dimensional accuracy,
high heat exchange efficiency, easy welding, corrosion resistance
and good formability.
Inner-grooved Tube Application fields
the connection of heat exchangers and pipeline systems in the air
conditioning and refrigeration industries.Inner-grooved
Tubesuitable for commercial air-conditioner heat exchanger, central
airr-conditioner dry evaporator, heat pipe radiator of electronic
products and solar equipment.
| Product name:Inner Grooved Copper Tube for solar equipment. |
| Nominal Size | Outer diameter | Bottom wall thickness | Fin height | Apex angle | Helix angle | Fin number | Unit weight |
| mm | mm | mm | ° | ° | N | g/m | |
| 5*0.20+0.14-18° | 5.00 | 0.20 | 0.14 | 20 | 18 | 40 | 33 |
| 7*0.20+0.10-18° | 7.00 | 0.20 | 0.10 | 40 | 18 | 65 | 47 |
| 7*0.23+0.10-30° | 7.00 | 0.23 | 0.10 | 40 | 30 | 60 | 48 |
| 7*0.23+0.13-35° | 7.00 | 0.23 | 0.13 | 10 | 35 | 65 | 48.5 |
| 7*0.24+0.18-18° | 7.00 | 0.24 | 0.18 | 15 | 18 | 50 | 54 |
| 7*0.25+0.18-18° | 7.00 | 0.25 | 0.18 | 40 | 18 | 50 | 57 |
| 7*0.30+0.15-18° | 7.00 | 0.30 | 0.15 | 40 | 18 | 65 | 64 |
| 7.94*0.24+0.18-18° | 7.94 | 0.24 | 0.18 | 40 | 18 | 50 | 60 |
| 7.94*0.40+0.18-18° | 7.94 | 0.40 | 0.18 | 30 | 18 | 60 | 95 |
| 9.52*0.27+0.16-18° | 9.52 | 0.27 | 0.16 | 30 | 18 | 60 | 81 |
| 9.52*0.41+0.20-18° | 9.52 | 0.41 | 0.20 | 30 | 18 | 60 | 116 |
| 9.52*0.50+0.15-18° | 9.52 | 0.50 | 0.15 | 30 | 18 | 60 | 138 |
| 9.52*0.50+0.20-18° | 9.52 | 0.50 | 0.20 | 50 | 18 | 60 | 140 |
|
|
